Rapid SL for WC

Product main features

• flushing cistern 80 mm
• 1.13 m installation height
• element width 0.62 m
• for on-the-wall installations or studded walls
• powder coated steel frame, self-supporting
• for dry-cladding, completely pre-assembled
• with fixed connections
• quick adjustment, lockable
• fixing material
• 2 WC fixing bolts
• fixing device for ceramic
• distance of fixing bolts 180/230 mm
• outlet bend Ø 80 mm
• depth adjustable
• transition Ø 80 mm
• inlet and outlet connecting set
• flushing cistern 80 mm, 6 - 9 l, containing following features:
• adjustment ex factory 6 l and 3 l
• pneumatic discharge valve offering 3 modes of operation: dual flush or start/stop or single flush
• water supply from top
• insulated against condensation
• low noise (group I acc. to German Noise Specification)
• angle valve 1/2"
• with push fit flexible hose union
• no tools required for the installation of the inspection shaft including protection during construction phase
• for vertical use
• without fixing brackets
• without flush plate/actuation
• GROHE Water Saving - Less water, perfect flow
