Rapid SL Element for WC with flushing cistern 80 mm, 1.13 m installation height

Product main features

• element width 0.62 m
• for small, narrow bathrooms
• for on-the-wall installations or studded walls
• powder coated steel frame, self-supporting
• for dry-cladding, completely pre-assembled
• with fixed connections
• quick adjustment, lockable
• fixing material
• TÜV approved
• 2 WC fixing bolts
• fixing device for ceramic
• distance of fixing bolts 180/230 mm
• PP outlet bend Ø 90 mm
• depth adjustable
• PP reducer Ø 90/110 mm
• inlet and outlet connecting set
• flushing cistern 80 mm, 6 - 9 l, containing following features:
• adjustment ex factory 6 l and 3 l
• pneumatic discharge valve offering 3 modes of operation: dual flush or start/stop or single flush
• water supply from top or back
• low noise (group I acc. to German Noise Specification)
• insulated against condensation
• water supply ½" and push fit flexible hose union
• no tools required for the installation of the inspection shaft including protection during construction phase
• for vertical use
• including wall brackets 38 558 00M for on-the-wall installation
• for mounting of small flush plates please order revision shaft 40 949 000 (sold separately)
• for installation in Scandinavia please order adapter 38 338 000 (sold separately)
